Home > Machinery > Forestry machinery > Hydraulic arm > Hydraulic arm STS NJ 85

Hydraulic arm STS NJ 85

Brand
STS
Range
8-9 m
Maximum range (m)
8.5
Lift at 4m (kg)
840
Lift at full extension (kg)
320
Rotation angle of arm (°)
360
Arm torque (kNm)
13.5
Grab area (m²)
0.24
Pumping pressure (bar)
190
Recommended pump output (l/min)
35-60
Total weight without legs (kg)
1100

Hydraulic arm STS NJ 85

STS Prachatice provides a wide range of hydraulic loaders for agricultural and forestry purposes designed especially for logging. Kesla hydraulic arms can be mounted on a forwarder or on a three-point linkage on a tractor.

Documents

Contact the seller

Hydraulic arm STS NJ 85
Hydraulic arm STS NJ 85
Hydraulic arm STS NJ 85
Hydraulic arm STS NJ 85
Hydraulic arm STS NJ 85
Hydraulic arm STS NJ 85
Hydraulic arm STS NJ 85
Hydraulic arm STS NJ 85
Hydraulic arm STS NJ 85
Hydraulic arm STS NJ 85
